Z Shape Corrugated Side Wall Belt Conveyor Machine Sealed And Environmental Friendly

Sealed And Environmental Friendly Z Shape Corrugated Side Wall Belt Conveyor

The Z Shape Corrugated Side Wall Belt Conveyor Machine is also known as the corrugated sidewall belt conveyor. It adopts a conveyor belt with corrugated sidewalls and diaphragms. It is a new type of continuous conveying equipment. Compared with the machine, the conveying capacity is increased by 1.5 to 2 times);

Z Shape Corrugated Side Wall Belt Conveyor Machine Sealed And Environmental Friendly

Tech data of Z Shape Corrugated Side Wall Belt Conveyor Machine

Belt Width(mm)		500		650		800
Side wall Height(mm)		80	120	120	160	120	160		200	240
Part angle throughput	30°	46	71	104	120	128	157		195	235
(m³/h)	45°	35	57	83	97	102	127		157	195
	60°	25	40	58	69	72	90		112	142
	90°	13	21	31	37	38	48		60	76
Dimensions	height of first rollerH2/h(mm)	1100-2000		1300-2000		1300-2000
	height of tail roller	600		600		600-800
	H2/h(mm)	600		600		600-800
	height of belt surface H2/h(mm)	760-800		800-850		800-1115
	width of ancho	870		1020		1220
	B2/h(mm)	870		1020		1220
Belt Width(mm)		1200				1400
Side wall Height(mm)		160	200	240	300	160	200	240	300	400
Part angle throughput	30°	275	331	419	466	319	395	500	564	794
(m³/h)	45°	222	267	347	384	258	318	414	465	680
	60°	158	190	253	178	184	226	302	337	524
	90°	85	102	136	149	98	121	162	180	281
Dimensions	height of first rollerH2/h(mm)	1400-2000		1600-2000
	height of belt surface H2/h(mm)	800-1000				800-1200
	height of belt surface H2/h(mm)	1050-1500				1050-1700
	width of ancho	1690				1890
	B2/h(mm)	1690				1890

Selection Conditions of Z Shape Corrugated Side Wall Belt Conveyor Machine

♦ Material to be processed: _____	♦ Max. granule size of the feeding material: _____mm
♦ Handling capacity (Ps. It means the total	♦ Percentage of Max. granule in material:_________%
material capacity feeding from the inlet): _____t/h	♦ Upstream equipment (Ps. It means what kind of
♦ Bulk Density: _____t/m3	equipment is used to feed the material): _____
♦ Material temperature: _____ºC;	♦ Downstream equipment (Ps. It means what kind of
♦ Water content:____%	equipment is used to discharge the material): _____
♦ Material is corrosive or not: ____ (Ps. Yes or No)	♦ Working power supply: _____V ______HZ
♦ Material is sticky or not: ____ (Ps. Yes or No)	♦ Please refer to the following picture and provide the
♦ Working environment is indoor or outdoor	relevant parameters:L1____m, L2___m, H___m, α____°
or indoor and outdoor: ______________	Working environment temperature: ______ ºC
